TETRA Plugs & Connectors
This product is an Axess manufactured and branded replacement item.
| TETRA PLUGS | ||
| PLUG TYPE | FITS | AUDIO SERIES |
| MOTOROLA Compatible Product | ||
MXP |
MOTOROLA MXP600 |
Please contact the sales team for further information |
MG3 |
MOTOROLA TETRA MTP700 & MTP850EX |
Available for all series except PSM remote speaker mic with emergency button |
MTH3 |
MOTOROLA MTH650, MTH800 MTP850 Side connector with locking screw |
Available for all series PSM Series (remote speaker mic) is only compatible with the ‘MTP850’ |
DP |
MOTOROLA MTP830S, MTP850S uses DP MTP6550, MTP6650, MTP6750 uses DP-A plug version |
Available for all series |
DP1 |
MOTOTRBO MTP3000 Series MTP3100, MTP3150, MTP3200 MTP3250, MTP3500, MTP3550 |
Available for all Mic & PTT except PSM remote speaker mic with emergency button & Listen Only |
M13 |
MOTOROLA MTP850 Bottom Connector |
Available for all series except Listen Only |
| NOKIA Compatible Product | ||
N1 |
EADS – NOKIA THR850,880,880i, 880i Light with charging jack |
Available for all series except PSM remote speaker mic with emergency button |
N2 |
EADS – NOKIA THR850 THR880 THR880i THR880i Light |
Available for all series except Listen Only & Remote speaker mic Accessories |
N3 |
EADS – NOKIA THR8, TH1N |
Available for all series except Listen Only & Remote speaker mic Accessories |
NA |
EADS – NOKIA THR9, THR9i |
Available for all series except Listen Only & Remote speaker mic Accessories |
MC1 |
JUPITER TPH700 |
Available for all series except Listen Only & Remote speaker mic Accessories |
| SEPURA Compatible Product | ||
SP |
SEPURA SRP2000, SRP3000, SRH3500, SRH3800, SRH3900 |
Available for all series except PSM Series (remote speaker mic) 304, 404 & 504 series |
SPS |
SEPURA SRP2000, SRP3000, SRH3500, SRH3800, SRH3900 With locking screw |
Available for all series except PSM Series (remote speaker mic) |
SP1 |
SEPURA SRP2000, SRP3000, SRH3500, SRH3800, SRP3900 Bottom connector with locking screw |
Available for all series |
SP2 |
SEPURA STP8000, STP8100, STP8200, STP9000, STP9100, STP9200, SC20, SC21 STP9038, STP8038 DMR: SBP8000 8310, 8040, 8340 8050, 8350, SCP8000 8010, 8310, 8040, 8340, 8050, 8350 SEP8000 8010, 8310, 8040, 8340, 8050, 8350 |
Available for all series |
